LG Display LC420WUE-SDP1 lembaran data, spesifikasi, stok, aplikasi www.looklcd-my.com
LookLCD LookLCD


LC420WUE-SDP1

LC420WUE-SDP1
LC420WUE-SDP1
LC420WUE-SDP1 thumb LC420WUE-SDP1 thumb
Jenama
LG Display
Saiz
42
Permohonan
LCTV
Resolusi
1920×1080
Komposisi
LCM
Kecerahan
380
CR
1000:1
Warna
16.7M/1.06B
Lampu latar
EEFL
Antara muka
LVDS
In Stock
1370
Spesifikasi

Nombor Bahagian LC420WUE-SDP1
JenamaLG Display
Saiz42
PermohonanLCTV
Resolusi1920×1080
KomposisiLCM
Kecerahan380
CR1000:1
Warna16.7M/1.06B
Lampu latarEEFL
Antara mukaLVDS
jenama panelLG Display
model panelLC420WUE-SDP1
jenis panel a-Si TFT-LCD , LCM
saiz panel42 inch
resolusi1920(RGB)×1080 , FHD
mod paparanIPS, Normally Black, Transmissive
kawasan aktif930.24×523.26 mm
garis besar983×576 mm
permukaanAntiglare (Haze 10%), Hard coating (2H)
kecerahan380 cd/m² (Typ.)
nisbah kontras1000:1 (Typ.)
warna paparan16.7M/1.06B (8-bit / 8-bit + Dithering), CIE193172%
masa tindak balas5 (Typ.)(G to G)
sudut pandangan89/89/89/89 (Min.)(CR≥10)(L/R/U/D)
kekerapan60Hz
jenis lampu14 pcsEEFLWithout Driver
antara muka isyaratLVDS (2 ch, 8/10-bit), 51 pins
voltan masukan12.0V (Typ.)
permohonanLCTV
Model Keluarga
LC420WU5-SLA1 LG Display 42 1920×1080
LC420WUD-SBT1 LG Display 42 1920×1080
LC420WUE-SCA2 LG Display 42 1920×1080
LC420WUE-SDP1 LG Display 42 1920×1080
LC420WUF-SBA1 LG Display 42 1920×1080
LC420WUG-SCA1 LG Display 42 1920×1080
LC420WUN-SAA1 LG Display 42 1920×1080
LC420WUN-SBD2 LG Display 42 1920×1080
LC420WUN-SCA1 LG Display 42 1920×1080
LC420WUN-SDA1 LG Display 42 1920×1080
