AUO T260XW02 VB lembaran data, spesifikasi, stok, aplikasi www.looklcd-my.com
LookLCD LookLCD


T260XW02 VB

T260XW02 VB
T260XW02 VB
T260XW02 VB thumb T260XW02 VB thumb
Jenama
AUO
Saiz
26.0
Permohonan
LCTV
Resolusi
1366×768
Komposisi
LCM
Kecerahan
500
CR
800:1
Warna
16.7M
Lampu latar
CCFL
Antara muka
LVDS
In Stock
81
Spesifikasi

Nombor Bahagian T260XW02 VB
JenamaAUO
Saiz26.0
PermohonanLCTV
Resolusi1366×768
KomposisiLCM
Kecerahan500
CR800:1
Warna16.7M
Lampu latarCCFL
Antara mukaLVDS
jenama panelAUO
model panelT260XW02 VB 0 Compatible model
jenis panel a-Si TFT-LCD , LCM
saiz panel26.0 inch
resolusi1366(RGB)×768 , WXGA
mod paparanVA, Normally Black, Transmissive
kawasan aktif575.769×323.712 mm
garis besar626×373 mm
permukaanAntiglare (Haze 13%), Hard coating (3H)
kecerahan500 cd/m² (Typ.)
nisbah kontras800:1 (Typ.)
warna paparan16.7M (8-bit), CIE193172%
masa tindak balas21/4 (Typ.)(Tr/Td); 8 (Typ.)(G to G)
sudut pandangan85/85/85/85 (Typ.)(CR≥10)(L/R/U/D)
kekerapan60Hz
jenis lampu14 pcsCCFLEmbedded (Inverter)
antara muka isyaratLVDS (1 ch, 8-bit), 30 pins
voltan masukan12.0V (Typ.)
permohonanLCTV
