| Nombor Bahagian | STCG057QVLAD-G00 |
| Jenama | Kyocera |
| Saiz | 5.7 |
| Permohonan | Industrial |
| Resolusi | 320×240 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 500:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | Parallel |
| pengilang | Kyocera |
| nama model | STCG057QVLAD-G00 |
| saiz skrin | 5.7 inch |
| jenis skrin | LCM , a-Si TFT-LCD |
| nombor piksel | 320(RGB)×240 (QVGA) 70PPI |
| susunan | RGB Vertical Stripe |
| kawasan aktif (mm) | 115.2 × 86.4 (H×V) |
| garis besar (mm) | - |
| kawasan bezel (mm) | - |
| rawatan | Glare (Haze 0%) |
| kecerahan | - |
| nisbah kontras | 500 : 1 (Typ.) (TM) |
| sudut pandangan | 80/80/80/80 (Typ.)(CR≥5) |
| tindak balas | 10/25 (Typ.)(Tr/Td) ms |
| pandangan yang baik di | - |
| mod kerja | TN, Normally White, Transmissive |
| kedalaman warna | 262K |
| lampu latar | WLED |
| jisim | - |
| digunakan untuk | Industrial |
| kadar segar semula | - |
| skrin sentuh | 4-wire Resistive Touch |
| jenis isyarat | Parallel RGB (1 ch, 6-bit) |
| bekalan voltan | 3.3V (Typ.) |
| maks. penilaian | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
