| Nombor Bahagian | S032Q10 |
| Jenama | CDTECH |
| Saiz | 3.2 |
| Permohonan | Handheld & PDA |
| Resolusi | 240×320 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 350:1 |
| Warna | 262K |
| Lampu latar | 1S5P |
| Antara muka | CPU |
| jenama panel | CDTECH |
| model panel | S032Q10 |
| saiz panel | 3.2" |
| jenis panel | a-Si TFT-LCD, LCM |
| resolusi | 240(RGB)×320, QVGA, 127PPI |
| format piksel | RGB Vertical Stripe |
| kawasan paparan | 47.88(W)×63.84(H) mm |
| pembukaan bezel | - |
| saiz garis besar | 55.04(W)×77.7(H) ×2.5(D) mm |
| permukaan | - |
| kecerahan | 270 cd/m² (Typ.) |
| nisbah kontras | 350:1 (Typ.) (TM) |
| sudut pandangan | 55/65/65/65 (Typ.)(CR≥10) |
| mod paparan | TN, Normally White, Transmissive |
| pandangan terbaik pada | 9 o'clock |
| masa tindak balas | 20 (Typ.)(Tr+Td) |
| warna paparan | 262K |
| jenis lampu | 1S5P WLED , 25K hours , Without Driver |
| kekerapan | - |
| skrin sentuh | Without |
| berat panel | TBD |
| permohonan | Handheld & PDA |
| antara muka isyarat | CPU , 37 pins FPC |
| voltan masukan | 3.3/3.3V (Max.)(VCC/IOVCC) |
| persekitaran | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
