| Nombor Bahagian | QV116FHB-N83-1QP0 |
| Jenama | BOE |
| Saiz | 11.6 |
| Permohonan | Digital Signage |
| Resolusi | 1920×1080 |
| Komposisi | CELL , a-Si TFT-LC |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | No |
| Antara muka | eDP |
| pengilang | BOE |
| nama model | QV116FHB-N83-1QP0 |
| saiz skrin | 11.6 inch |
| jenis skrin | CELL , a-Si TFT-LCD |
| nombor piksel | 1920(RGB)×1080 (FHD) 190PPI |
| susunan | RGB Vertical Stripe |
| kawasan aktif (mm) | 256.32 × 144.18 (H×V) |
| garis besar (mm) | 261.62 × 155.3 × 1.16 (H×V×D) |
| kawasan bezel (mm) | - |
| rawatan | Clear, Hard coating (3H) |
| kecerahan | 0 cd/m² |
| nisbah kontras | 1000 : 1 (Typ.) (TM) |
| sudut pandangan | 80/80/80/80 (Typ.)(CR≥10) |
| tindak balas | 30 (Typ.)(Tr+Td) ms |
| pandangan yang baik di | Symmetry |
| mod kerja | ADS, Normally Black, Transmissive |
| ketebalan kaca | 0.40+0.40 mm |
| ketransmisian | 4.2% (Typ.) |
| kedalaman warna | 16.7M 72% NTSC |
| lampu latar | No B/L , With LED Driver |
| jisim | 103g |
| digunakan untuk | Digital Signage |
| kadar segar semula | 60Hz |
| skrin sentuh | Without |
| senarai ic pemandu | Built-in COG 4 source chips |
| jenis isyarat | eDP (2 Lanes) , 30 pins Connector |
| bekalan voltan | 3.3V (Typ.) |
| maks. penilaian | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
