LP116WF1-SPA1

LP116WF1-SPA1
LP116WF1-SPA1
LP116WF1-SPA1 thumb LP116WF1-SPA1 thumb
Jenama
LG Display
Saiz
11.6
Permohonan
NBPC
Resolusi
1920×1080
Komposisi
Assembly
Kecerahan
360
CR
600:1
Warna
262K
Lampu latar
WLED
Antara muka
eDP
In Stock
1161
Spesifikasi

Nombor Bahagian LP116WF1-SPA1
JenamaLG Display
Saiz11.6
PermohonanNBPC
Resolusi1920×1080
KomposisiAssembly
Kecerahan360
CR600:1
Warna262K
Lampu latarWLED
Antara mukaeDP
jenama panelLG Display
model panelLP116WF1-SPA1
jenis panel a-Si TFT-LCD , Assembly
saiz panel11.6 inch
resolusi1920(RGB)×1080 , FHD
kawasan aktif256.32×144.18 mm
garis besar267×157.8×4.03 mm
gaya bentukSlim (PCBA Flat, Depth ≤3.2mm)
permukaanAnti Fingerprint, Hard coating (8H)
kecerahan360 cd/m² (Typ.)
nisbah kontras600:1 (Typ.)
warna paparan262K (6-bit)
sudut pandangan80/80/80/80 (Min.)(CR≥10)(L/R/U/D)
kekerapan60Hz
antara muka isyarateDP (2 Lanes), 35 pins
voltan masukan3.3V (Typ.)
permohonanNBPC
