| Nombor Bahagian | QD15TL04 Rev.05 |
| Jenama | QDI |
| Saiz | 15.4 |
| Permohonan | NBPC |
| Resolusi | 1280×800 |
| Komposisi | LCM |
| Kecerahan | 165 |
| CR | 350:1 |
| Warna | 262K |
| Lampu latar | CCFL |
| Antara muka | LVDS |
| jenama panel | QDI |
| model panel | QD15TL04 Rev.05 7 Compatible model |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 15.4 inch |
| resolusi | 1280(RGB)×800 , WXGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 331.2×207 mm |
| garis besar | 344×242.2×6.5 mm |
| gaya bentuk | Wedge (PCBA Bent, Depth ≥5.2mm) |
| permukaan | Glare (Haze 0%), Hard coating (3H), Antireflection |
| kecerahan | 165 cd/m² (Typ.) |
| nisbah kontras | 350:1 (Typ.) |
| warna paparan | 262K (6-bit) |
| masa tindak balas | 8/17 (Typ.)(Tr/Td) |
| sudut pandangan | 40/40/10/30 (Min.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 1 pcsCCFLWithout Driver |
| antara muka isyarat | LVDS (1 ch, 6-bit), 30 pins |
| voltan masukan | 3.3V (Typ.) |
| rohs: | |
| permohonan | NBPC |
| B154PW02 V0 | AUO | 15.4 | 1440×900 |
| LP154WX4-TLC8 | LG Display | 15.4 | 1280×800 |
| LP154WX5-TLA1 | LG Display | 15.4 | 1280×800 |
| LP154WX5-TLB2 | LG Display | 15.4 | 1280×800 |
| LTN154CT03-D01 | Samsung | 15.4 | 1920×1200 |
| LTN154P1-L03 | Samsung | 15.4 | 1680×1050 |
| LTN154U2-L03 | Samsung | 15.4 | 1920×1200 |
| LTN154X3-L0D | Samsung | 15.4 | 1280×800 |
| QD15TL04 Rev.04 | QDI | 15.4 | 1280×800 |
| QD15TL04 Rev.05 | QDI | 15.4 | 1280×800 |
| CLAA156WA15A | CPT | 15.6 | 1366×768 |
| G075ADE-T01 | Innolux | 7.5 | 1200×900 |
| LP140WH1-TLA1 | LG Display | 14.0 | 1366×768 |
| LP140WH2-TLL1 | LG Display | 14.0 | 1366×768 |
| LTN121AT08 | Samsung | 12.1 | 1280×800 |
| LTN133AT03-001 | Samsung | 13.3 | 1280×800 |
| LTN133AT05-001 | Samsung | 13.3 | 1280×800 |
| LTN133YL01-L01 | Samsung | 13.3 | 3200×1800 |
| LTN173HT02-D02 | Samsung | 17.3 | 1920×1080 |
| LTN173HT02-X01 | Samsung | 17.3 | 1920×1080 |
