| Nombor Bahagian | OC550DQH-5000 |
| Jenama | No Brand |
| Saiz | 55 |
| Permohonan | Digital Signage Outd |
| Resolusi | 3840×2160 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 1200:1 |
| Warna | 16.7M/1.07B |
| Lampu latar | WLED |
| Antara muka | V-by-One |
| jenama | No Brand |
| saiz pepenjuru | 55 inch |
| format piksel | 3840(RGB)×2160 [UHD] 80PPI |
| kawasan aktif | 1209.6(H)×680.4(V) mm |
| kawasan bezel | - |
| kecerahan | 5000 cd/m² (Typ.) |
| arah pandang | Symmetry |
| sudut pandangan | 89/89/89/89 (Min.)(CR≥10) |
| warna sokongan | 16.7M/1.07B 72% NTSC |
| berat badan | 15.5Kgs (Typ.) |
| kadar bingkai | 60Hz |
| jenis antara muka | V-by-One 8 lane , 51 pins Connector |
| bekalan kuasa | 12.0V (Typ.) |
| persekitaran | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| model | OC550DQH-5000 |
| menaip | a-Si TFT-LCD , LCM |
| konfigurasi | RGB Vertical Stripe |
| garis besar malap. | 1246.6(H)×715.5(V) ×68(D) mm |
| rawatan | Antiglare (Haze 1%), Hard coating (3H) |
| nisbah kontras | 1200:1 (Typ.) (TM) |
| masa tindak balas | 8 (Typ.)(G to G) |
| mod operasi | IPS, Normally Black, Transmissive |
| sumber cahaya | WLED , 30K hours , W/O Driver |
| direka untuk | Digital Signage Outdoor High Brightness |
| panel sentuh | Without |
