| Nombor Bahagian | NV116WHM-T1C |
| Jenama | BOE |
| Saiz | 11.6 |
| Permohonan | Laptop |
| Resolusi | 1366×768 |
| Komposisi | a-Si TFT-LCD , Assem |
| Kecerahan | |
| CR | 800:1 |
| Warna | 262K |
| Lampu latar | 8S3P |
| Antara muka | eDP |
| jenama panel | BOE |
| saiz panel | 11.6" |
| resolusi | 1366(RGB)×768, WXGA, 135PPI |
| kawasan paparan | 256.125(W)×144(H) mm |
| saiz garis besar | 284.85(W)×189.84(H) ×4.2(D) mm |
| kecerahan | 220 cd/m² (Typ.) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| pandangan terbaik pada | Symmetry |
| warna paparan | 262K 50% NTSC |
| kekerapan | 60Hz |
| gaya bentuk | Slim (PCBA Flat, T≤3.2mm) |
| antara muka isyarat | eDP (2 Lanes) , 40 pins Connector |
| voltan masukan | 3.3V (Typ.) |
| persekitaran | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| model panel | NV116WHM-T1C (BOE08B4) |
| jenis panel | a-Si TFT-LCD , Assembly |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | - |
| permukaan | Hard coating (7H) |
| nisbah kontras | 800:1 (Typ.) (TM) |
| mod paparan | - |
| masa tindak balas | 30 (Typ.)(Tr+Td) |
| jenis lampu | 8S3P WLED , 15K hours , With LED Driver |
| skrin sentuh | On-Cell Touch |
| permohonan | Laptop |
| A116XW02 V0 | AUO | 11.6 | 1366×768 |
| B116HAT03.1 | AUO | 11.6 | 1920×1080 |
| LP116WF1-SPA1 | LG Display | 11.6 | 1920×1080 |
| LP116WH6-SPA2 | LG Display | 11.6 | 1366×768 |
| M116NWR1 R7 | IVO | 11.6 | 1366×768 |
| M116NWR6 R0 | IVO | 11.6 | 1366×768 |
| N116B6-L07 | Innolux | 11.6 | 1366×768 |
| N116BGE-LB1 | Innolux | 11.6 | 1366×768 |
| N116HSE-EA2 | Innolux | 11.6 | 1920×1080 |
| N116HSE-EJ1 | Innolux | 11.6 | 1920×1080 |
