| Nombor Bahagian | NL3224AC35-09 |
| Jenama | NEC |
| Saiz | 5.5 |
| Permohonan | Industrial |
| Resolusi | 320×240 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 400:1 |
| Warna | 262K |
| Lampu latar | - |
| Antara muka | |
| jenama panel | NEC |
| saiz panel | 5.5" |
| resolusi | 320(RGB)×240, QVGA, 72PPI |
| kawasan paparan | 111.36(W)×83.52(H) mm |
| kecerahan | - |
| sudut pandangan | - |
| pandangan terbaik pada | - |
| warna paparan | 262K |
| kekerapan | 60Hz |
| berat badan | - |
| model panel | NL3224AC35-09 |
| jenis panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | - |
| nisbah kontras | 400:1 (Typ.) (TM) |
| mod paparan | TN, Normally White, Transmissive |
| masa tindak balas | 5/25 (Typ.)(Tr/Td) |
| jenis lampu | |
| skrin sentuh | Without |
| permohonan | Industrial |
