| Nombor Bahagian | NL3224BC35-22 |
| Jenama | NLT |
| Saiz | 5.5 |
| Permohonan | IA |
| Resolusi | 320×240 |
| Komposisi | LCM |
| Kecerahan | 750 |
| CR | 500:1 |
| Warna | 262K |
| Lampu latar | CCFL |
| Antara muka | TTL |
| jenama panel | NEC |
| model panel | NL3224BC35-22 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 5.5 inch |
| resolusi | 320(RGB)×240 , QVGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 111.36×83.52 mm |
| garis besar | 134×104.5 mm |
| permukaan | Clear, Hard coating (2H), Antireflection |
| kecerahan | 750 cd/m² (Typ.) |
| nisbah kontras | 500:1 (Typ.) |
| warna paparan | 262K (6-bit), CIE193150% |
| masa tindak balas | 5/25 (Typ.)(Tr/Td) |
| sudut pandangan | 55/55/50/40 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 2 pcsCCFLWithout Driver |
| antara muka isyarat | CMOS (1 ch, 6-bit), 33 pins |
| voltan masukan | 3.3/5.0V (Typ.)(VCC) |
| permohonan | IA |
