| Nombor Bahagian | NL10276AC24-05 |
| Jenama | NLT |
| Saiz | 12.1 |
| Permohonan | DMPC |
| Resolusi | 1024×768 |
| Komposisi | LCM |
| Kecerahan | 200 |
| CR | 150:1 |
| Warna | Full color |
| Lampu latar | CCFL |
| Antara muka | Analog |
| jenama panel | NEC |
| model panel | NL10276AC24-05 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 12.1 inch |
| resolusi | 1024(RGB)×768 , XGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 245.76×184.32 mm |
| garis besar | 290×225×17 mm |
| permukaan | |
| kecerahan | 200 cd/m² (Typ.) |
| nisbah kontras | 150:1 (Typ.) |
| warna paparan | Full color , CIE193140% |
| masa tindak balas | 40 (Max.)(Tr) |
| sudut pandangan | 50/50/20/20 (Typ.)(CR≥10)(L/R/U/D) |
| jenis lampu | 2 pcsCCFLEmbedded (Inverter) |
| antara muka isyarat | Analog RGB, 31 pins |
| voltan masukan | 3.3/12V (Typ.)(VCC/VDD) |
| permohonan | DMPC |
