| Nombor Bahagian | N161HCA-EA3 |
| Jenama | Innolux |
| Saiz | 16.1 |
| Permohonan | Laptop |
| Resolusi | 1920×1080 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | eDP |
| pengilang | Innolux |
| nama model | N161HCA-EA3 (CMN1604) |
| saiz skrin | 16.1 inch |
| jenis skrin | LCM , a-Si TFT-LCD |
| nombor piksel | 1920(RGB)×1080 (FHD) 137PPI |
| susunan | RGB Vertical Stripe |
| kawasan aktif (mm) | 355.39 × 199.91 (H×V) |
| garis besar (mm) | 361.9 × 222.16 × 3.2 (H×V×D) |
| kawasan bezel (mm) | - |
| rawatan | Antiglare, Hard coating (3H) |
| kecerahan | 300 cd/m² (Typ.) |
| nisbah kontras | 1000 : 1 (Typ.) (TM) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| tindak balas | 11/9 (Typ.)(Tr/Td) ms |
| pandangan yang baik di | Symmetry |
| mod kerja | AAS, Normally Black, Transmissive |
| kedalaman warna | 16.7M 100% sRGB |
| lampu latar | WLED , 15K hours , With LED Driver |
| bentuk garis besar | Slim (PCBA Flat, T≤3.2mm) |
| digunakan untuk | Laptop |
| kadar segar semula | 60Hz |
| skrin sentuh | Without |
| jenis isyarat | eDP (2 Lanes) , eDP1.2 , 30 pins Connector |
| bekalan voltan | 3.3V (Typ.) |
| maks. penilaian | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| TX41D96VC1FAA | KOE | 16.1 | 1400×1050 |
| TX41D97VC1HAA | KOE | 16.1 | 1400×1050 |
