| Nombor Bahagian | TX41D97VC1HAA |
| Jenama | KOE |
| Saiz | 16.1 |
| Permohonan | NBPC |
| Resolusi | 1400×1050 |
| Komposisi | LCM |
| Kecerahan | 330 |
| CR | 600:1 |
| Warna | 262K |
| Lampu latar | CCFL |
| Antara muka | LVDS |
| jenama panel | HITACHI |
| model panel | TX41D97VC1HAA |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 16.1 inch |
| resolusi | 1400(RGB)×1050 , SXGA+ |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 326.55×244.913 mm |
| gaya bentuk | Wedge (PCBA Bent, Depth ≥5.2mm) |
| permukaan | Glare (Haze 0%), Hard coating (2H), Reflection 1.2% (Typ.) |
| kecerahan | 330 cd/m² (Typ.) |
| nisbah kontras | 600:1 (Typ.) |
| warna paparan | 262K (6-bit) |
| masa tindak balas | 30/20 (Typ.)(Tr/Td) |
| sudut pandangan | 65/65/50/50 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 2 pcsCCFLWithout Driver |
| antara muka isyarat | LVDS (2 ch, 6-bit), 30 pins |
| voltan masukan | 3.3V (Typ.) |
| permohonan | NBPC |
| TX41D96VC1FAA | KOE | 16.1 | 1400×1050 |
| TX41D97VC1HAA | KOE | 16.1 | 1400×1050 |
| B101EW02 V0 | AUO | 10.1 | 1280×720 |
| B140XW01 V9 | AUO | 14.0 | 1366×768 |
| CLAA154WB05AN | CPT | 15.4 | 1280×800 |
| HB140FH1-301 | BOE | 14.0 | 1920×1080 |
| LP141WX5-TLD1 | LG Display | 14.1 | 1280×800 |
| LTN154U2-L04-0 | Samsung | 15.4 | 1920×1200 |
| LTN156AT01-D02 | Samsung | 15.6 | 1366×768 |
| N133I7-L01 | Innolux | 13.3 | 1280×800 |
| N156BGE-EB1 | Innolux | 15.6 | 1366×768 |
| TM150SP-02L01 | SANYO | 15.0 | 1400×1050 |
