| Nombor Bahagian | N156HCA-EAB |
| Jenama | Innolux |
| Saiz | 15.6 |
| Permohonan | Laptop |
| Resolusi | 1920×1080 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 700:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | eDP |
| jenama | Innolux |
| saiz pepenjuru | 15.6 inch |
| format piksel | 1920(RGB)×1080 [FHD] 141PPI |
| kawasan aktif | 344.16(H)×193.59(V) mm |
| kawasan bezel | - |
| kecerahan | 250 cd/m² (Typ.) |
| arah pandang | Symmetry |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| warna sokongan | 16.7M 45% NTSC |
| gaya bentuk | Slim (PCBA Flat, T≤3.2mm) |
| kadar bingkai | 60Hz |
| jenis antara muka | eDP (2 Lanes) , eDP1.2 , 30 pins Connector |
| bekalan kuasa | 3.3V (Typ.) |
| persekitaran | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| model | N156HCA-EAB (CMN15E7) |
| menaip | a-Si TFT-LCD , LCM |
| konfigurasi | RGB Vertical Stripe |
| garis besar malap. | 350.66(H)×216.25(V) ×3.2(D) mm |
| rawatan | Antiglare, Hard coating (3H) |
| nisbah kontras | 700:1 (Typ.) (TM) |
| masa tindak balas | 14/11 (Typ.)(Tr/Td) |
| mod operasi | AAS, Normally Black, Transmissive |
| sumber cahaya | WLED , 15K hours , With LED Driver |
| direka untuk | Laptop |
| panel sentuh | Without |
