| Nombor Bahagian | MT236FHM-N10 |
| Jenama | BOE |
| Saiz | 23.6 |
| Permohonan | Desktop Monitor Gami |
| Resolusi | 1920×1080 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| pengilang | BOE |
| nama model | MT236FHM-N10 |
| saiz skrin | 23.6 inch |
| jenis skrin | LCM , a-Si TFT-LCD |
| nombor piksel | 1920(RGB)×1080 (FHD) 93PPI |
| susunan | RGB Vertical Stripe |
| kawasan aktif (mm) | 521.28 × 293.22 (H×V) |
| garis besar (mm) | 544.18 × 320.5 × 13.1 (H×V×D) |
| kawasan bezel (mm) | 525.22 × 297.22 (H×V) |
| rawatan | Antiglare (Haze 25%), Hard coating (3H) |
| kecerahan | 300 cd/m² (Typ.) |
| nisbah kontras | 1000 : 1 (Typ.) (TM) |
| sudut pandangan | 85/85/80/80 (Typ.)(CR≥10) |
| tindak balas | 1.5/3.5 (Typ.)(Tr/Td) ms |
| pandangan yang baik di | - |
| mod kerja | TN, Normally White, Transmissive |
| kedalaman warna | 16.7M 76% NTSC |
| lampu latar | WLED , 30K hours , No Driver |
| jisim | 2.06Kgs (Typ.) |
| digunakan untuk | Desktop Monitor Gaming |
| kadar segar semula | 144Hz |
| skrin sentuh | Without |
| jenis isyarat | LVDS (4 ch, 8-bit) , 92 pins Connector |
| bekalan voltan | 5.0V (Typ.) |
| maks. penilaian | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
