| Nombor Bahagian | MLAF061WE51 X |
| Jenama | Mantix |
| Saiz | 6.1 |
| Permohonan | Mobile Phone |
| Resolusi | 720×1560 |
| Komposisi | a-Si TFT-LCD, CELL |
| Kecerahan | |
| CR | 1500:1 |
| Warna | 16.7M |
| Lampu latar | No |
| Antara muka | |
| jenama panel | Mantix |
| model panel | MLAF061WE51 X |
| saiz panel | 6.1" |
| jenis panel | a-Si TFT-LCD, CELL |
| resolusi | 720(RGB)×1560, 282PPI |
| format piksel | RGB Vertical Stripe |
| kawasan paparan | 64.8(W)×140.4(H) mm |
| pembukaan bezel | - |
| saiz garis besar | 66.6(W)×145.3(H) ×0.3(D) mm |
| permukaan | Without Polarizer |
| kecerahan | 0 cd/m² |
| nisbah kontras | 1500:1 (Typ.) (TM) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| mod paparan | FFS, Normally Black, Transmissive |
| pandangan terbaik pada | Symmetry |
| masa tindak balas | 25 (Typ.)(Tr+Td) |
| kedalaman kaca | 0.15+0.15 mm |
| ketransmisian | 3.9% (Typ.)(with Polarizer) |
| warna paparan | 16.7M 72% NTSC |
| jenis lampu | No B/L |
| kekerapan | - |
| skrin sentuh | In-Cell Touch |
| ic pemandu | COGSuggest ICNL9911, FT8006P, ILI9881H, ICNL9911S, NT36525B, HX83102-D |
| berat panel | - |
| permohonan | Mobile Phone |
| voltan masukan | 1.8/5.5/-5.5V (Typ.)(IOICC/VSP/VSN) |
| persekitaran | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| A061FW01 V0 | AUO | 6.1 | 480×234 |
| C061FW01 V0 | AUO | 6.1 | 480×234 |
| CLAA061LA0ACW | CPT | 6.1 | 800×480 |
| K6488L-FF | CITIZEN | 6.1 | 640×480 |
| LA061WQ1-TD04 | LG Display | 6.1 | 480×272 |
| LA061WQ1-TD05 | LG Display | 6.1 | 480×272 |
| LQ061Y1VG01 | SHARP | 6.1 | 800×480 |
| LQ61D133 | SHARP | 6.1 | 640×480 |
| LTA061B2E0F | TOSHIBA | 6.1 | |
| PM061WX1 | E Ink | 6.1 | 800×480 |
