AUO M240HW02 V5 lembaran data, spesifikasi, stok, aplikasi www.looklcd-my.com
LookLCD LookLCD


M240HW02 V5

M240HW02 V5
M240HW02 V5
M240HW02 V5 thumb M240HW02 V5 thumb
Jenama
AUO
Saiz
24.0
Permohonan
DMPC
Resolusi
1920×1080
Komposisi
LCM
Kecerahan
350
CR
5000:1
Warna
16.7M
Lampu latar
WLED
Antara muka
LVDS
In Stock
12769
Spesifikasi

Nombor Bahagian M240HW02 V5
JenamaAUO
Saiz24.0
PermohonanDMPC
Resolusi1920×1080
KomposisiLCM
Kecerahan350
CR5000:1
Warna16.7M
Lampu latarWLED
Antara mukaLVDS
jenama panelAUO
model panelM240HW02 V5
jenis panel a-Si TFT-LCD , LCM
saiz panel24.0 inch
resolusi1920(RGB)×1080 , FHD
mod paparanVA, Normally Black, Transmissive
kawasan aktif531.36×298.89 mm
garis besar556×323.2 mm
permukaanAntiglare, Hard coating (3H)
kecerahan350 cd/m² (Typ.)
nisbah kontras5000:1 (Typ.)
warna paparan16.7M (8-bit), CIE193172%
masa tindak balas7/5 (Typ.)(Tr/Td)
sudut pandangan89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
kekerapan120Hz
jenis lampu20S4P×2CNWLEDWithout Driver
antara muka isyaratLVDS (4 ch, 8-bit), 66 pins
voltan masukan5.0V (Typ.)
permohonanDMPC
Model Keluarga
M240HTN01.1 AUO 24.0 1920×1080
M240HVN01.0 AUO 24.0 1920×1080
M240HVN02.0 AUO 24.0 1920×1080
M240HW01 V0 AUO 24.0 1920×1080
M240HW01 V1 AUO 24.0 1920×1080
M240HW01 V2 AUO 24.0 1920×1080
M240HW01 VB AUO 24.0 1920×1080
M240HW01 VC AUO 24.0 1920×1080
M240HW02 V6 AUO 24.0 1920×1080
M240HW02 V7 AUO 24.0 1920×1080
Produk Panas
HM215WU3-100 BOE 21.5 1920×1080
LM185WH1-TLF4 LG Display 18.5 1366×768
LM215WF2-SLD1 LG Display 21.5 1920×1080
LM215WF3-SLD1 LG Display 21.5 1920×1080
LM270WQ1-SDA2 LG Display 27.0 2560×1440
LTM185AT05 Samsung 18.5 1366×768
LTM220CS01 Samsung 22.0 1920×1200
M270H1-L01 Innolux 27.0 1920×1080
MT220WW01 V.6 Innolux 22.0 1680×1050
NA19020-C961 Fujitsu 19.0 1280×1024
