M170EG01 V9

M170EG01 V9
M170EG01 V9
M170EG01 V9 thumb M170EG01 V9 thumb
Jenama
AUO
Saiz
17.0
Permohonan
DMPC
Resolusi
1280×1024
Komposisi
LCM
Kecerahan
420
CR
500:1
Warna
16.2M
Lampu latar
CCFL
Antara muka
LVDS
In Stock
123
Spesifikasi

Nombor Bahagian M170EG01 V9
JenamaAUO
Saiz17.0
PermohonanDMPC
Resolusi1280×1024
KomposisiLCM
Kecerahan420
CR500:1
Warna16.2M
Lampu latarCCFL
Antara mukaLVDS
jenama panelAUO
model panelM170EG01 V9 1 Compatible model
jenis panel a-Si TFT-LCD , LCM
saiz panel17.0 inch
resolusi1280(RGB)×1024 , SXGA
mod paparanTN, Normally White, Transmissive
kawasan aktif337.92×270.336 mm
garis besar358.5×296.5×17.5 mm
permukaanGlare (Haze 0%), Hard coating (2H)
kecerahan420 cd/m² (Typ.)
nisbah kontras500:1 (Typ.)
warna paparan16.2M (6-bit + FRC), CIE193172%
masa tindak balas6/2 (Typ.)(Tr/Td)
sudut pandangan70/70/70/60 (Typ.)(CR≥10)(L/R/U/D)
kekerapan60Hz
jenis lampu4 pcsCCFLWithout Driver
antara muka isyaratLVDS (2 ch, 8-bit), 30 pins
voltan masukan5.0V (Typ.)
permohonanDMPC
Model Keluarga
M170E8-L01 Innolux 17.0 1280×1024
M170EG01 V5 AUO 17.0 1280×1024
M170EG01 V7 AUO 17.0 1280×1024
M170EG01 V8 AUO 17.0 1280×1024
M170EG01 VF AUO 17.0 1280×1024
M170EG01 VG AUO 17.0 1280×1024
M170EN01 V9 AUO 17.0 1280×1024
M170EN04 V6 AUO 17.0 1280×1024
M170EP01 V2 AUO 17.0 1280×1024
M170ETN01.1 AUO 17.0 1280×1024
