| Nombor Bahagian | M090AWP4 R0 |
| Jenama | IVO |
| Saiz | 9.0 |
| Permohonan | Outdoor High Brightn |
| Resolusi | 800×480 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 700:1 |
| Warna | 262K |
| Lampu latar | 8S3P |
| Antara muka | Parallel |
| jenama panel | IVO |
| saiz panel | 9.0" |
| resolusi | 800(RGB)×480, WVGA, 104PPI |
| kawasan paparan | 198(W)×112.08(H) mm |
| saiz garis besar | 210.82(W)×126.96(H) ×6.4(D) mm |
| kecerahan | 750 cd/m² (Typ.) |
| sudut pandangan | 70/70/50/70 (Typ.)(CR≥10) |
| pandangan terbaik pada | 6 o'clock |
| warna paparan | 262K 70% NTSC |
| kekerapan | 60Hz |
| berat panel | 251g (Max.) |
| antara muka isyarat | Parallel RGB (1 ch, 6-bit) , 60 pins FPC |
| voltan masukan | 3.3/11.6/22/-7V (Typ.)(VCC/VDDA/VGH/VGL) |
| persekitaran | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 90 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| model panel | M090AWP4 R0 |
| jenis panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | 200.2(W)×114.28(H) mm |
| permukaan | Antiglare, Hard coating (3H) |
| nisbah kontras | 700:1 (Typ.) (TM) |
| mod paparan | TN, Normally White, Transmissive |
| masa tindak balas | 12 (Typ.)(Tr+Td) |
| jenis lampu | 8S3P WLED , 30K hours , Without Driver |
| skrin sentuh | Without |
| permohonan | Outdoor High Brightness Automotive Display |
| A090VW01 V3 | AUO | 9.0 | 800×480 |
| AT090TN10 | Innolux | 9.0 | 800×480 |
| AT090TN23 | Innolux | 9.0 | 1280×800 |
| CLAA090LC41CW | CPT | 9.0 | 800×480 |
| ED090NA-01H | Innolux | 9.0 | 1280×800 |
| EE090NA-01C | Innolux | 9.0 | 1280×800 |
| G090VTN02.0 | AUO | 9.0 | 800×480 |
| NL8048BC24-12 | NLT | 9.0 | 800×480 |
| T-55562D090J-LW-A-AAN | Kyocera | 9.0 | 800×480 |
| TX23D85VM0BAA | KOE | 9.0 | 1280×768 |
