| Nombor Bahagian | M090AWA5 R0 |
| Jenama | IVO |
| Saiz | 9.0 |
| Permohonan | Outdoor High Brightn |
| Resolusi | 1280×720 |
| Komposisi | LCM, a-Si TFT-LCD |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | 7S4P |
| Antara muka | |
| pengilang | IVO |
| nama model | M090AWA5 R0 |
| saiz skrin | 9.0 inch |
| jenis skrin | LCM, a-Si TFT-LCD |
| nombor piksel | 1280(RGB)×720 (WXGA) 163PPI |
| susunan | RGB Vertical Stripe |
| kawasan aktif (mm) | 198.72 × 111.78 (H×V) |
| garis besar (mm) | 212.2 × 127.5 × 10.5 (H×V×D) |
| kawasan bezel (mm) | 201.72 × 114.78 (H×V) |
| rawatan | Antiglare, Hard coating (3H), Reflection 6.0% (Max.) |
| kecerahan | 880 cd/m² (Typ.) |
| nisbah kontras | 1000 : 1 (Typ.) (TM) |
| sudut pandangan | 80/80/80/80 (Typ.)(CR≥10) |
| tindak balas | 30 (Typ.)(Tr+Td) ms |
| pandangan yang baik di | Symmetry |
| mod kerja | IPS, Normally Black, Transmissive |
| kedalaman warna | 16.7M 70% NTSC |
| lampu latar | 7S4P WLED , 15K hours , No Driver |
| jisim | 335g (Max.) |
| digunakan untuk | Outdoor High Brightness Automotive Display |
| kadar segar semula | 60Hz |
| skrin sentuh | Without |
| Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
