| Nombor Bahagian | M080AWP9 R0 |
| Jenama | IVO |
| Saiz | 8.0 |
| Permohonan | Automotive Display |
| Resolusi | 800×480 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 700:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | Parallel |
| jenama | IVO |
| model | M080AWP9 R0 |
| saiz pepenjuru | 8.0 inch |
| menaip | a-Si TFT-LCD, LCM |
| format piksel | 800(RGB)×480 [WVGA] 115PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 175.2(H)×105.12(V) mm |
| garis besar malap. | 186.5(H)×117.22(V) ×6.65(D) mm |
| kawasan bezel | 177.4(H)×107.32(V) mm |
| rawatan | Antiglare |
| kecerahan | 750 cd/m² (Typ.) |
| nisbah kontras | 700:1 (Typ.) (TM) |
| arah pandang | - |
| masa tindak balas | 13 (Typ.)(Tr+Td) |
| sudut pandangan | 70/70/50/70 (Typ.)(CR≥10) |
| mod operasi | TN, Normally White, Transmissive |
| warna sokongan | 262K 70% NTSC |
| sumber cahaya | WLED [7S3P] , 30K hours , W/O Driver |
| berat badan | 195/215g (Typ./Max.) |
| direka untuk | Automotive Display |
| kadar bingkai | 60Hz |
| panel sentuh | Without |
| jenis antara muka | Parallel RGB (1 ch, 6-bit) , 60 pins FPC |
| bekalan kuasa | 3.3/10.6/22/-7.0V (Typ.)(VCC/VDDA/VGH/VGL) |
| persekitaran | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C |
