| Nombor Bahagian | LTY400HC01 |
| Jenama | Samsung |
| Saiz | 40 |
| Permohonan | LCTV |
| Resolusi | 1920×1080 |
| Komposisi | LCM |
| Kecerahan | 550 |
| CR | 2000:1 |
| Warna | 1.07B |
| Lampu latar | CCFL |
| Antara muka | LVDS |
| jenama panel | S-LCD |
| model panel | LTY400HC01 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 40 inch |
| resolusi | 1920(RGB)×1080 , FHD |
| mod paparan | S-PVA, Normally Black, Transmissive |
| kawasan aktif | 885.6×498.15 mm |
| garis besar | 952×551×54.2 mm |
| permukaan | Hard coating (3H) |
| kecerahan | 550 cd/m² (Typ.) |
| nisbah kontras | 2000:1 (Typ.) |
| warna paparan | 1.07B (10-bit), CIE193190% |
| masa tindak balas | 8/6 (Typ.)(Tr/Td); 8 (Typ.)(G to G) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 120Hz |
| jenis lampu | 20 pcsCCFLEmbedded (Balance board) |
| antara muka isyarat | LVDS (4 ch, 10-bit), 92 pins |
| voltan masukan | 12.0V (Typ.) |
| permohonan | LCTV |
