| Nombor Bahagian | LTN156AT17-D01 |
| Jenama | Samsung |
| Saiz | 15.6 |
| Permohonan | NBPC |
| Resolusi | 1366×768 |
| Komposisi | LCM |
| Kecerahan | 220 |
| CR | 500:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama panel | SAMSUNG |
| model panel | LTN156AT17-D01 16 Compatible model |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 15.6 inch |
| resolusi | 1366(RGB)×768 , WXGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 344.232×193.536 mm |
| garis besar | 359.3×209.5×5.5 mm |
| gaya bentuk | Wedge (PCBA Bent, Depth ≥5.2mm) |
| permukaan | Glare (Haze 0%), Hard coating (3H) |
| kecerahan | 220 cd/m² (Typ.) |
| nisbah kontras | 500:1 (Min.) |
| warna paparan | 262K (6-bit), CIE193160% |
| masa tindak balas | 16 (Typ.)(Tr+Td) |
| sudut pandangan | 40/40/10/30 (Min.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 9S4PWLEDEmbedded (LED Driver) |
| antara muka isyarat | LVDS (1 ch, 6-bit), 40 pins |
| voltan masukan | 3.3V (Typ.) |
| permohonan | NBPC |
| LTN156AT01-B01 | Samsung | 15.6 | 1366×768 |
| LTN156AT01-B02 | Samsung | 15.6 | 1366×768 |
| LTN156AT05-701 | Samsung | 15.6 | 1366×768 |
| LTN156AT05-B01 | Samsung | 15.6 | 1366×768 |
| LTN156AT16-401 | Samsung | 15.6 | 1366×768 |
| LTN156AT17-D02 | Samsung | 15.6 | 1366×768 |
| LTN156AT19-W01 | Samsung | 15.6 | 1366×768 |
| LTN156AT24-L01 | Samsung | 15.6 | 1366×768 |
| LTN156AT24-P01 | Samsung | 15.6 | 1366×768 |
| LTN156AT35-W01 | Samsung | 15.6 | 1366×768 |
| B133EW01 V3 | AUO | 13.3 | 1280×800 |
| B133XW03 V1 | AUO | 13.3 | 1366×768 |
| B140HAN01.3 | AUO | 14.0 | 1920×1080 |
| BT140GW02 V.0 | Innolux | 14.0 | 1366×768 |
| CLAA154WB09A | CPT | 15.4 | 1280×800 |
| HB156WX1-100 | BOE | 15.6 | 1366×768 |
| LP141WX5-TLP3 | LG Display | 14.1 | 1280×800 |
| LP171WU5-TLB1 | LG Display | 17.1 | 1920×1200 |
| LQ170M1LA4B | SHARP | 17.0 | 1920×1200 |
| LTN150PF-L04 | Samsung | 15.0 | 1400×1050 |
