LTN154X5-L02


Jenama
Samsung
Saiz
15.4
Permohonan
NBPC
Resolusi
1280×800
Komposisi
LCM
Kecerahan
490
CR
700:1
Warna
262K
Lampu latar
CCFL
Antara muka
LVDS
In Stock
293
Spesifikasi

Nombor Bahagian LTN154X5-L02
JenamaSamsung
Saiz15.4
PermohonanNBPC
Resolusi1280×800
KomposisiLCM
Kecerahan490
CR700:1
Warna262K
Lampu latarCCFL
Antara mukaLVDS
jenama panelSAMSUNG
model panelLTN154X5-L02
jenis panel a-Si TFT-LCD , LCM
saiz panel15.4 inch
resolusi1280(RGB)×800 , WXGA
mod paparanTN, Normally White, Transmissive
kawasan aktif331.2×207 mm
garis besar344×224×10.5 mm
gaya bentukWedge (PCBA Bent, Depth ≥5.2mm)
permukaanGlare (Haze 0%), Hard coating (3H)
kecerahan490 cd/m² (Typ.)
nisbah kontras700:1 (Typ.)
warna paparan262K (6-bit), CIE193172%
masa tindak balas16 (Typ.)(Tr+Td)
sudut pandangan65/65/60/60 (Typ.)(CR≥10)(L/R/U/D)
kekerapan60Hz
jenis lampu2 pcsCCFLWithout Driver
antara muka isyaratLVDS (1 ch, 6-bit), 30 pins
voltan masukan3.3V (Typ.)
rohs:
permohonanNBPC
