Samsung LTN154X3-L09-0 lembaran data, spesifikasi, stok, aplikasi www.looklcd-my.com
LookLCD LookLCD


LTN154X3-L09-0

LTN154X3-L09-0
LTN154X3-L09-0
LTN154X3-L09-0
LTN154X3-L09-0 thumb LTN154X3-L09-0 thumb LTN154X3-L09-0 thumb
Jenama
Samsung
Saiz
15.4
Permohonan
NBPC
Resolusi
1280×800
Komposisi
LCM
Kecerahan
160
CR
300:1
Warna
262K
Lampu latar
CCFL
Antara muka
LVDS
In Stock
13331
Spesifikasi

Nombor Bahagian LTN154X3-L09-0
JenamaSamsung
Saiz15.4
PermohonanNBPC
Resolusi1280×800
KomposisiLCM
Kecerahan160
CR300:1
Warna262K
Lampu latarCCFL
Antara mukaLVDS
jenama panelSAMSUNG
model panelLTN154X3-L09-0
jenis panel a-Si TFT-LCD , LCM
saiz panel15.4 inch
resolusi1280(RGB)×800 , WXGA
mod paparanTN, Normally White, Transmissive
kawasan aktif331.2×207 mm
garis besar344×222×6.5 mm
gaya bentukWedge (PCBA Bent, Depth ≥5.2mm)
permukaanGlare (Haze 0%), Hard coating (3H)
kecerahan160 cd/m² (Typ.)
nisbah kontras300:1 (Min.)
warna paparan262K (6-bit)
masa tindak balas25 (Typ.)(Tr+Td)
sudut pandangan50/50/35/50 (Typ.)(CR≥10)(L/R/U/D)
kekerapan60Hz
jenis lampu1 pcsCCFLEmbedded (Inverter)
antara muka isyaratLVDS (1 ch, 6-bit), 30 pins
voltan masukan3.3V (Typ.)
permohonanNBPC
Model Keluarga
LTN154X1-L01 Samsung 15.4 1280×800
LTN154X1-L03 Samsung 15.4 1280×800
LTN154X2-L02 Samsung 15.4 1280×800
LTN154X3-L01 Samsung 15.4 1280×800
LTN154X3-L04 Samsung 15.4 1280×800
LTN154X3-L09-G Samsung 15.4 1280×800
LTN154X3-L0D Samsung 15.4 1280×800
LTN154X3-L0D-G Samsung 15.4 1280×800
LTN154X9-L02 Samsung 15.4 1280×800
LTN154XB-L01 Samsung 15.4 1280×800
Produk Panas
B133EW03 V2 AUO 13.3 1280×800
B154SW01 V9 AUO 15.4 1680×1050
B156HAK01.0 AUO 15.6 1920×1080
LP133WH2-TLL2 LG Display 13.3 1366×768
LP140WD1-TLM1 LG Display 14.0 1600×900
LTD121EQ3B TOSHIBA 12.1 1280×800
LTN140KT13-B01 Samsung 14.0 1600×900
LTN154X3-L0D-G Samsung 15.4 1280×800
LTN190W1-L01 Samsung 19.0 1680×1050
N156HGE-LG1 Innolux 15.6 1920×1080
