| Nombor Bahagian | LTM300M1-P02 |
| Jenama | Samsung |
| Saiz | 30.0 |
| Permohonan | DMPC |
| Resolusi | 2560×1600 |
| Komposisi | LCM |
| Kecerahan | 300 |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | CCFL |
| Antara muka | TMDS |
| jenama panel | SAMSUNG |
| model panel | LTM300M1-P02 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 30.0 inch |
| resolusi | 2560(RGB)×1600 , WQXGA |
| mod paparan | S-PVA, Normally Black, Transmissive |
| kawasan aktif | 641.28×400.8 mm |
| garis besar | 677.3×436.8 mm |
| permukaan | Antiglare (Haze 44%), Hard coating (3H) |
| kecerahan | 300 cd/m² (Typ.) |
| nisbah kontras | 1000:1 (Typ.) |
| warna paparan | 16.7M (8-bit), CIE1931100% |
| masa tindak balas | 12 (Typ.)(Tr+Td); 6 (Typ.)(G to G) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 16 pcsCCFLEmbedded (Inverter) |
| antara muka isyarat | Dual Link TMDS, 45 pins |
| voltan masukan | 18.0V (Typ.) |
| permohonan | DMPC |
