| Nombor Bahagian | LTM270TT01 |
| Jenama | Samsung |
| Saiz | 27.0 |
| Permohonan | DMPC |
| Resolusi | 2048×1152 |
| Komposisi | LCM |
| Kecerahan | 400 |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | CCFL |
| Antara muka | LVDS |
| jenama panel | SAMSUNG |
| model panel | LTM270TT01 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 27.0 inch |
| resolusi | 2048(RGB)×1152 , WDXGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 597.5×336.1 mm |
| garis besar | 631.4×370 mm |
| permukaan | Antiglare (Haze 25%), Hard coating (3H) |
| kecerahan | 400 cd/m² (Typ.) |
| nisbah kontras | 1000:1 (Typ.) |
| warna paparan | 16.7M (6-bit + Hi-FRC), CIE193192% |
| masa tindak balas | 5 (Typ.)(Tr+Td) |
| sudut pandangan | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | CCFLEmbedded (Inverter) |
| antara muka isyarat | LVDS (2 ch, 8-bit), 30 pins |
| voltan masukan | 5.0V (Typ.) |
| permohonan | DMPC |
| LM270WF4-TLA1 | LG Display | 27.0 | 1920×1080 |
| LTM270DL02 | Samsung | 27.0 | 2560×1440 |
| LTM270DL04 | Samsung | 27.0 | 2560×1440 |
| LTM270DL06 | Samsung | 27.0 | 2560×1440 |
| LTM270HL02 | Samsung | 27.0 | 1920×1080 |
| LTM270HT03 | Samsung | 27.0 | 1920×1080 |
| LTM270RL01 | Samsung | 27.0 | 5120×2880 |
| LTM270TT01 | Samsung | 27.0 | 2048×1152 |
| M270HGE-L20 | Innolux | 27.0 | 1920×1080 |
| M270HW01 V0 | AUO | 27.0 | 1920×1080 |
| LM190E08-TLL3 | LG Display | 19.0 | 1280×1024 |
| LM201U05-SLA3 | LG Display | 20.1 | 1600×1200 |
| LM215WF4-TRA1 | LG Display | 21.5 | 1920×1080 |
| LQ150X1DG11 | SHARP | 15.0 | 1024×768 |
| LTM15C423S | TOSHIBA | 15.0 | 1024×768 |
| M200HJJ-L20 | Innolux | 19.5 | 1920×1080 |
| M220Z1-L01 | Innolux | 22.0 | 1680×1050 |
| M220Z1-L03 | Innolux | 22.0 | 1680×1050 |
| M240HTN01.1 | AUO | 24.0 | 1920×1080 |
| M240HW01 VB | AUO | 24.0 | 1920×1080 |
