LTM220M1-L02(Glare)

LTM220M1-L02(Glare)
LTM220M1-L02(Glare)
LTM220M1-L02(Glare)
LTM220M1-L02(Glare) thumb LTM220M1-L02(Glare) thumb LTM220M1-L02(Glare) thumb
Jenama
Samsung
Saiz
22.0
Permohonan
DMPC
Resolusi
1680×1050
Komposisi
LCM
Kecerahan
400
CR
1000:1
Warna
16.7M
Lampu latar
CCFL
Antara muka
LVDS
In Stock
17908
Spesifikasi

Nombor Bahagian LTM220M1-L02(Glare)
JenamaSamsung
Saiz22.0
PermohonanDMPC
Resolusi1680×1050
KomposisiLCM
Kecerahan400
CR1000:1
Warna16.7M
Lampu latarCCFL
Antara mukaLVDS
jenama panelSAMSUNG
model panelLTM220M1-L02(Glare)
jenis panel a-Si TFT-LCD , LCM
saiz panel22.0 inch
resolusi1680(RGB)×1050 , WSXGA+
mod paparanTN, Normally White, Transmissive
kawasan aktif473.76×296.1 mm
garis besar493.7×320.1 mm
permukaanGlare (Haze 0%), Hard coating (2H), Antireflection
kecerahan400 cd/m² (Typ.)
nisbah kontras1000:1 (Typ.)
warna paparan16.7M , CIE193172%
masa tindak balas5 (Typ.)(Tr+Td)
sudut pandangan80/80/80/80 (Typ.)(CR≥10)(L/R/U/D)
kekerapan60Hz
jenis lampu4 pcsCCFLWithout Driver
antara muka isyaratLVDS (2 ch, 8-bit), 30 pins
voltan masukan5.0V (Typ.)
permohonanDMPC
