| Nombor Bahagian | LTL106HL01-001 |
| Jenama | Samsung |
| Saiz | 10.6 |
| Permohonan | PAD |
| Resolusi | 1920×1080 |
| Komposisi | LCM |
| Kecerahan | 400 |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama panel | SAMSUNG |
| model panel | LTL106HL01-001 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 10.6 inch |
| resolusi | 1920(RGB)×1080 , FHD |
| mod paparan | PLS, Normally Black, Transmissive |
| kawasan aktif | 234.72×132.03 mm |
| garis besar | 246.52×149.02×5.2 mm |
| permukaan | Glare (Haze 0%), Hard coating (2H) |
| kecerahan | 400 cd/m² (Typ.) |
| nisbah kontras | 800:1 (Typ.) |
| warna paparan | 16.7M (8-bit), CIE193150% |
| masa tindak balas | 16 (Typ.)(Tr+Td) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 9S4PWLEDEmbedded (LED Driver) |
| antara muka isyarat | LVDS (2 ch, 8-bit), 51 pins |
| voltan masukan | 3.3V (Typ.) |
| permohonan | PAD |
