LTA400HF30-W

LTA400HF30-W
LTA400HF30-W
LTA400HF30-W
LTA400HF30-W thumb LTA400HF30-W thumb LTA400HF30-W thumb
Jenama
Samsung
Saiz
40
Permohonan
LCTV
Resolusi
1920×1080
Komposisi
LCM
Kecerahan
350
CR
5000:1
Warna
1.07B
Lampu latar
WLED
Antara muka
LVDS
In Stock
373
Spesifikasi

Nombor Bahagian LTA400HF30-W
JenamaSamsung
Saiz40
PermohonanLCTV
Resolusi1920×1080
KomposisiLCM
Kecerahan350
CR5000:1
Warna1.07B
Lampu latarWLED
Antara mukaLVDS
jenama panelSAMSUNG
model panelLTA400HF30-W
jenis panel a-Si TFT-LCD , LCM
saiz panel40 inch
resolusi1920×1080(RGB) , FHD
mod paparanS-PVA, Normally Black, Transmissive
kawasan aktif885.6×498.15 mm
garis besar912.4×527.6×29.9 mm
permukaanAntiglare (Haze 2%), Hard coating (2H)
kecerahan350 cd/m² (Typ.)
nisbah kontras5000:1 (Typ.)
warna paparan1.07B (8-bit + Hi-FRC), CIE193170%
masa tindak balas8 (Typ.)(G to G)
sudut pandangan89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
kekerapan120Hz (60Hz Input)
jenis lampuWLEDWithout Driver
antara muka isyaratLVDS (2 ch, 10-bit), 61 pins
voltan masukan12.0V (Typ.)
permohonanLCTV
