| Nombor Bahagian | LSI490HN01-V |
| Jenama | SAMSUNG |
| Saiz | 49 |
| Permohonan | Digital Signage |
| Resolusi | 1920×1080 |
| Komposisi | a-Si TFT-LCD, CELL |
| Kecerahan | |
| CR | 4000:1 |
| Warna | 1.07B |
| Lampu latar | No |
| Antara muka | LVDS |
| jenama | SAMSUNG |
| model | LSI490HN01-V |
| saiz pepenjuru | 49 inch |
| menaip | a-Si TFT-LCD, CELL |
| format piksel | 1920(RGB)×1080 [FHD] 45PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 1073.78(H)×604(V) mm |
| garis besar malap. | 1083.78(H)×615.5(V) ×1.3(D) mm |
| kawasan bezel | - |
| rawatan | Antiglare (Haze 25%), Hard coating (2H) |
| kecerahan | 0 cd/m² |
| nisbah kontras | 4000:1 (Typ.) (TM) |
| arah pandang | Symmetry |
| masa tindak balas | 6 (Typ.)(G to G) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| mod operasi | SPVA, Normally Black, Transmissive |
| ketebalan plat | 0.40+0.50 mm |
| penghantaran | 6.79% (Typ.)(with Polarizer) |
| warna sokongan | 1.07B 99% sRGB |
| sumber cahaya | No B/L |
| berat badan | 1.80±0.18Kgs |
| direka untuk | Digital Signage |
| kadar bingkai | 60Hz |
| panel sentuh | Without |
| perincian d-ic | COF Built-in 6 source chips |
| jenis antara muka | LVDS (2 ch, 10-bit) , 51 pins Connector |
| bekalan kuasa | 12.0V (Typ.) |
| persekitaran | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 65 °C |
| HV490FHB-N80 | BOE | 49 | 1920×1080 |
| LC490DUJ-SGE3 | LG Display | 49 | 1920×1080 |
| LC490DUY-SHA1 | LG Display | 49 | 1920×1080 |
| LC490DUY-SHA2 | LG Display | 49 | 1920×1080 |
| LC490EGE-FHM1 | LG Display | 49 | 3840×2160 |
| LC490EQJ-SGK1 | LG Display | 49 | 3840×2160 |
| LC490EUE-FHM1 | LG Display | 49 | 1920×1080 |
| MT4851D01-1 | CSOT | 49 | 3840×2160 |
| ST4851D01-2 | CSOT | 49 | 3840×2160 |
