| Nombor Bahagian | LSC490HN05-W |
| Jenama | SAMSUNG |
| Saiz | 49 |
| Permohonan | TV Sets |
| Resolusi | 1920×1080 |
| Komposisi | a-Si TFT-LCD , CELL |
| Kecerahan | |
| CR | 6000:1 |
| Warna | 16.7M |
| Lampu latar | No |
| Antara muka | LVDS |
| jenama | SAMSUNG |
| saiz pepenjuru | 49 inch |
| format piksel | 1920×1080(RGB) [FHD] 45PPI |
| kawasan aktif | 1073.78(H)×604(V) mm |
| kawasan bezel | - |
| kecerahan | 0 cd/m² |
| arah pandang | Symmetry |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| ketebalan plat | - |
| warna sokongan | 16.7M 99% NTSC |
| berat badan | 1.70Kgs (Typ.) |
| kadar bingkai | 60Hz |
| perincian d-ic | COF Built-in 2 source chips |
| jenis antara muka | LVDS (2 ch, 10-bit) , 51 pins Connector |
| bekalan kuasa | 12.0V (Typ.) |
| persekitaran | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 65 °C |
| model | LSC490HN05-W |
| menaip | a-Si TFT-LCD , CELL |
| konfigurasi | RGB Horizontal Stripe |
| garis besar malap. | 1078.78(H)×617.8(V) ×1.3(D) mm |
| rawatan | Antiglare (Haze 2.3%), Hard coating (2H) |
| nisbah kontras | 6000:1 (Typ.) (TM) |
| masa tindak balas | 8 (Typ.)(G to G) |
| mod operasi | SVA, Normally Black, Transmissive |
| penghantaran | 6.9% (Typ.)(with Polarizer) |
| sumber cahaya | No B/L |
| direka untuk | TV Sets |
| panel sentuh | Without |
