| Nombor Bahagian | LQ9D03B |
| Jenama | SHARP |
| Saiz | 8.4 |
| Permohonan | IA |
| Resolusi | 640×480 |
| Komposisi | LCM |
| Kecerahan | 70 |
| CR | 100:1 |
| Warna | 4096 |
| Lampu latar | CCFL |
| Antara muka | TTL |
| jenama panel | SHARP |
| model panel | LQ9D03B |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 8.4 inch |
| resolusi | 640(RGB)×480 , VGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 170.88×129.6 mm |
| garis besar | 242.5×179.4 mm |
| permukaan | Antiglare (Haze 25%), Hard coating (2H) |
| kecerahan | 70 cd/m² (Typ.) |
| nisbah kontras | 100:1 (Typ.) |
| warna paparan | 4096 (4-bit) |
| masa tindak balas | 30/50 (Typ.)(Tr/Td) |
| sudut pandangan | 35/35/10/30 (Min.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 1 pcsCCFLWithout Driver |
| antara muka isyarat | Parallel RGB (1 ch, 4-bit), 31 pins |
| voltan masukan | 5.0V (Typ.)(VCC) |
| permohonan | IA |
