| Nombor Bahagian | LQ080M1SX01 |
| Jenama | Sharp |
| Saiz | 8.0 |
| Permohonan | Pad & Tablet |
| Resolusi | 1200×1920 |
| Komposisi | Oxide TFT-LCD , LCM |
| Kecerahan | |
| CR | 1500:1 |
| Warna | 16.7M |
| Lampu latar | 5S5P |
| Antara muka | |
| jenama panel | Sharp |
| saiz panel | 8.0" |
| resolusi | 1200(RGB)×1920, WUXGA, 284PPI |
| kawasan paparan | 107.28(W)×171.648(H) mm |
| saiz garis besar | 112.38(W)×182.75(H) ×3.19(D) mm |
| kecerahan | 500 cd/m² (Typ.) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| pandangan terbaik pada | Symmetry |
| warna paparan | 16.7M 90% NTSC |
| kekerapan | 75Hz |
| berat badan | 67g (Max.) |
| model panel | LQ080M1SX01 |
| jenis panel | Oxide TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | - |
| permukaan | Clear, Hard coating |
| nisbah kontras | 1500:1 (Typ.) (TM) |
| mod paparan | IPS, Normally Black, Transmissive |
| masa tindak balas | 30 (Typ.)(Tr+Td) |
| jenis lampu | 5S5P WLED , 15K hours , Without Driver |
| skrin sentuh | Without |
| permohonan | Pad & Tablet |
