| Nombor Bahagian | LQ042Q1DW40P |
| Jenama | Sharp |
| Saiz | 4.2 |
| Permohonan | Portable Navigation |
| Resolusi | 320×320 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | Parallel |
| jenama | Sharp |
| model | LQ042Q1DW40P |
| saiz pepenjuru | 4.2 inch |
| menaip | a-Si TFT-LCD, LCM |
| format piksel | 320(RGB)×320 [QVGA] 108PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 84.96(H)×63.72(V) mm |
| garis besar malap. | 96.8(H)×71.5(V) mm |
| kawasan bezel | - |
| rawatan | Antiglare, Hard coating (3H) |
| kecerahan | 180 cd/m² (Typ.) |
| nisbah kontras | 800:1 (Typ.) (TM) |
| arah pandang | - |
| masa tindak balas | 35/35 (Typ.)(Tr/Td) |
| sudut pandangan | 80/80/80/80 (Typ.)(CR≥10) |
| mod operasi | TN, Normally White, Transmissive |
| warna sokongan | 16.7M |
| sumber cahaya | WLED [6S1P] , W/O Driver |
| berat badan | 39.0g (Typ.) |
| direka untuk | Portable Navigation |
| kadar bingkai | 60Hz |
| panel sentuh | Without |
| jenis antara muka | Parallel RGB (1 ch, 8-bit) , 53 pins FPC |
| bekalan kuasa | 1.8/5.0/-5.0/14.5/-14.5V (Typ.)(VSHD/VSHA/GVSS/VGH/VGL) |
| persekitaran | Operating Temperature: 0 ~ 40 °C ; Storage Temperature: -25 ~ 60 °C |
