| Nombor Bahagian | LQ035Q1DH01 |
| Jenama | SHARP |
| Saiz | 3.5 |
| Permohonan | DSC |
| Resolusi | 320×240 |
| Komposisi | LCM |
| Kecerahan | 400 |
| CR | 300:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | TTL |
| jenama panel | SHARP |
| model panel | LQ035Q1DH01 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 3.5 inch |
| resolusi | 320(RGB)×240 , QVGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 70.56×52.92 mm |
| garis besar | 76.9×63.9×4.7 mm |
| permukaan | Antiglare, Hard coating (2H) |
| kecerahan | 400 cd/m² (Typ.) |
| nisbah kontras | 300:1 (Typ.) |
| warna paparan | 262K (6-bit) |
| masa tindak balas | 30/30 (Typ.)(Tr/Td) |
| sudut pandangan | 45/45/20/55 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 7S1PWLEDWithout Driver |
| antara muka isyarat | Parallel RGB (1 ch, 6-bit) + SPI, 67 pins |
| voltan masukan | 3.3/3.3V (Typ.)(VDDIO/VCI) |
| permohonan | DSC |
