| Nombor Bahagian | LQ024B7UD01 |
| Jenama | SHARP |
| Saiz | 2.4 |
| Permohonan | MPH |
| Resolusi | 160×240 |
| Komposisi | LCM |
| Kecerahan | 28 |
| CR | 110:1 |
| Warna | 65K |
| Lampu latar | WLED |
| Antara muka | CPU |
| jenama panel | SHARP |
| model panel | LQ024B7UD01 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 2.4 inch |
| resolusi | 160(RGB)×240 , HQVGA |
| mod paparan | TN, Normally White, Transflective |
| kawasan aktif | 33.6×50.4 mm |
| garis besar | 41.8×66.6 mm |
| permukaan | Hard coating (3H) |
| kecerahan | 28 cd/m² (Typ.) |
| nisbah kontras | 110:1 (Typ.)(Transmissive)12:1 (Typ.)(Reflective) |
| warna paparan | 65K |
| masa tindak balas | 30/50 (Typ.)(Tr/Td) |
| sudut pandangan | 50/50/60/50 (Typ.)(CR≥10)(L/R/U/D) |
| jenis lampu | 2S1PWLEDWithout Driver |
| antara muka isyarat | CPU, 24 pins |
| voltan masukan | 3.3V (Typ.) |
| permohonan | MPH |
