| Nombor Bahagian | LP154WX2-TL01 |
| Jenama | LG Display |
| Saiz | 15.4 |
| Permohonan | NBPC |
| Resolusi | 1280×800 |
| Komposisi | LCM |
| Kecerahan | 200 |
| CR | 550:1 |
| Warna | 262K |
| Lampu latar | CCFL |
| Antara muka | LVDS |
| jenama panel | LG.Philips LCD |
| model panel | LP154WX2-TL01 11 Compatible model |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 15.4 inch |
| resolusi | 1280(RGB)×800 , WXGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 331.2×207 mm |
| garis besar | 344×222×6.5 mm |
| gaya bentuk | Wedge (PCBA Bent, Depth ≥5.2mm) |
| permukaan | Antiglare, Hard coating (2H), Antireflection |
| kecerahan | 200 cd/m² (Typ.) |
| nisbah kontras | 550:1 (Typ.) |
| warna paparan | 262K (6-bit) |
| masa tindak balas | 16 (Typ.)(Tr+Td) |
| sudut pandangan | 65/65/50/50 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 1 pcsCCFLWithout Driver |
| antara muka isyarat | LVDS (1 ch, 6-bit), 30 pins |
| voltan masukan | 3.3V (Typ.) |
| permohonan | NBPC |
| LP154W01-A3 | LG Display | 15.4 | 1280×800 |
| LP154W01-TLF1 | LG Display | 15.4 | 1280×800 |
| LP154WE2-TLB1 | LG Display | 15.4 | 1680×1050 |
| LP154WE3-TLA2 | LG Display | 15.4 | 1680×1050 |
| LP154WE3-TLB1 | LG Display | 15.4 | 1680×1050 |
| LP154WP2-TLC2 | LG Display | 15.4 | 1440×900 |
| LP154WU1-TLB1 | LG Display | 15.4 | 1920×1200 |
| LP154WX5-TLA1 | LG Display | 15.4 | 1280×800 |
| LP154WX7-TLA3 | LG Display | 15.4 | 1280×800 |
| LP154WX7-TLP1 | LG Display | 15.4 | 1280×800 |
| B141XG10 V0 | AUO | 14.1 | 1024×768 |
| B156HW02 V1 | AUO | 15.6 | 1920×1080 |
| HB140WX1-300 | BOE | 14.0 | 1366×768 |
| LP140WD1-TLA1 | LG Display | 14.0 | 1600×900 |
| LP140WH4-TLD1 | LG Display | 14.0 | 1366×768 |
| LP141WX3-TLN1 | LG Display | 14.1 | 1280×800 |
| LQ133K1LA04 | SHARP | 13.3 | 1280×800 |
| LT104V3-100 | Samsung | 10.4 | 640×480 |
| LTN154AT09-201 | Samsung | 15.4 | 1280×800 |
| N134B6-L04 | Innolux | 13.4 | 1366×768 |
