| Nombor Bahagian | LP116WH8-SPA1 |
| Jenama | LG Display |
| Saiz | 11.6 |
| Permohonan | Laptop |
| Resolusi | 1366×768 |
| Komposisi | LCM, a-Si TFT-LCD |
| Kecerahan | |
| CR | 800:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | eDP |
| pengilang | LG Display |
| nama model | LP116WH8-SPA1 (LGD0500) |
| saiz skrin | 11.6 inch |
| jenis skrin | LCM, a-Si TFT-LCD |
| nombor piksel | 1366(RGB)×768 (WXGA) 135PPI |
| susunan | RGB Vertical Stripe |
| kawasan aktif (mm) | 256.125 × 144 (H×V) |
| garis besar (mm) | 278 × 168 × 3.2 (H×V×D) |
| kawasan bezel (mm) | 260.15 × 147.5 (H×V) |
| rawatan | Glare (Haze 0%) |
| kecerahan | 250 cd/m² (Typ.) |
| nisbah kontras | 800 : 1 (Typ.) (TM) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| tindak balas | 35 (Typ.)(Tr+Td) ms |
| pandangan yang baik di | Symmetry |
| mod kerja | IPS, Normally Black, Transmissive |
| kedalaman warna | 262K 48% NTSC |
| lampu latar | WLED , 15K hours , With LED Driver |
| bentuk garis besar | Slim (PCBA Flat, T≤3.2mm) |
| digunakan untuk | Laptop |
| kadar segar semula | 60Hz |
| skrin sentuh | In-Cell Touch |
| jenis isyarat | eDP (1 Lane) , HBR1 (2.7G/lane) , Connector 40 pins |
| bekalan voltan | 3.3V (Typ.) |
| maks. penilaian | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
