| Nombor Bahagian | LP101WX1-SLN2 |
| Jenama | LG Display |
| Saiz | 10.1 |
| Permohonan | PAD |
| Resolusi | 1280×800 |
| Komposisi | LCM |
| Kecerahan | 350 |
| CR | 500:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama panel | LG Display |
| model panel | LP101WX1-SLN2 1 Compatible model |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 10.1 inch |
| resolusi | 1280(RGB)×800 , WXGA |
| mod paparan | IPS, Normally Black, Transmissive |
| kawasan aktif | 216.96×135.6 mm |
| garis besar | 241.86×161.6×5.2 mm |
| permukaan | Glare (Haze 0%), Reflection 1.5% (Typ.) |
| kecerahan | 350 cd/m² (Typ.) |
| nisbah kontras | 500:1 (Min.) |
| warna paparan | 262K (6-bit) |
| masa tindak balas | 35 (Typ.)(Tr+Td); 24 (Typ.)(G to G) |
| sudut pandangan | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | WLEDEmbedded (LED Driver) |
| antara muka isyarat | LVDS (1 ch, 6-bit), 40 pins |
| voltan masukan | 3.3V (Typ.) |
| permohonan | PAD |
| LP101WH1-TLA3 | LG Display | 10.1 | 1366×768 |
| LP101WH1-TLP1 | LG Display | 10.1 | 1366×768 |
| LP101WH4-SLAB | LG Display | 10.1 | 1366×768 |
| LP101WH4-SLP2 | LG Display | 10.1 | 1366×768 |
| LP101WS1-TLB3 | LG Display | 10.1 | 1024×576 |
| LP101WSA-TLB1 | LG Display | 10.1 | 1024×600 |
| LP101WX1-SLB1 | LG Display | 10.1 | 1280×800 |
| LP101WX1-SLP2 | LG Display | 10.1 | 1280×800 |
| LP101WX2-SLA1 | LG Display | 10.1 | 1280×800 |
| LP101WX2-SLP1 | LG Display | 10.1 | 1280×800 |
| B079XAN01.0 | AUO | 7.9 | 768×1024 |
| BP070WS1-400 | BOE | 7.0 | 1024×600 |
| HE070IA-04M | Innolux | 7.0 | 800×1280 |
| HT121WX2-210 | HYDIS | 12.1 | 1280×800 |
| HX104X01-210 | HYDIS | 10.4 | 1024×768 |
| LPM089A001A | JDI | 8.9 | 2560×1600 |
| LTN121AP06-301 | Samsung | 12.1 | 1280×800 |
| N070ICE-G02 Rev.A2 | Innolux | 7.0 | 800×1280 |
| P070ACB-DB1 | Innolux | 7.0 | 600×1024 |
| TM080TDHG01 | Tianma | 8.0 | 1024×768 |
