| Nombor Bahagian | LM230WF7-SSB3 |
| Jenama | LG Display |
| Saiz | 23.0 |
| Permohonan | Desktop Monitor |
| Resolusi | 1920×1080 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | |
| jenama | LG Display |
| saiz pepenjuru | 23.0 inch |
| format piksel | 1920(RGB)×1080 [FHD] 95PPI |
| kawasan aktif | 509.184(H)×286.416(V) mm |
| kecerahan | - |
| arah pandang | Symmetry |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| warna sokongan | 16.7M 72% NTSC |
| berat badan | - |
| kadar bingkai | 60Hz |
| model | LM230WF7-SSB3 |
| menaip | a-Si TFT-LCD , LCM |
| konfigurasi | RGB Vertical Stripe |
| garis besar malap. | - |
| nisbah kontras | 1000:1 (Typ.) (TM) |
| masa tindak balas | 14 (Typ.)(G to G) |
| mod operasi | IPS, Normally Black, Transmissive |
| sumber cahaya | WLED |
| direka untuk | Desktop Monitor |
| panel sentuh | In-Cell Touch |
