LM230WF5-TLH1

LM230WF5-TLH1
LM230WF5-TLH1 thumb
Jenama
LG Display
Saiz
23.0
Permohonan
DMPC
Resolusi
1920×1080
Komposisi
LCM
Kecerahan
250
CR
600:1
Warna
16.7M
Lampu latar
WLED
Antara muka
LVDS
In Stock
10008
Spesifikasi

Nombor Bahagian LM230WF5-TLH1
JenamaLG Display
Saiz23.0
PermohonanDMPC
Resolusi1920×1080
KomposisiLCM
Kecerahan250
CR600:1
Warna16.7M
Lampu latarWLED
Antara mukaLVDS
jenama panelLG Display
model panelLM230WF5-TLH1
jenis panel a-Si TFT-LCD , LCM
saiz panel23.0 inch
resolusi1920(RGB)×1080 , FHD
mod paparanTN, Normally White, Transmissive
kawasan aktif509.184×286.416 mm
garis besar533.2×312×10.7 mm
permukaanAntiglare, Hard coating (3H)
kecerahan250 cd/m² (Typ.)
nisbah kontras600:1 (Typ.)
warna paparan16.7M (6-bit + Hi-FRC), CIE193172%
masa tindak balas1.3/3.7 (Typ.)(Tr/Td)
sudut pandangan45/45/15/35 (Typ.)(CR≥10)(L/R/U/D)
kekerapan60Hz
jenis lampu2 stringsWLEDWithout Driver
antara muka isyaratLVDS (2 ch, 8-bit), 30 pins
voltan masukan5.0V (Typ.)
permohonanDMPC
