LG Display LM215WF3-SLC1 lembaran data, spesifikasi, stok, aplikasi www.looklcd-my.com

LM215WF3-SLC1


Jenama
LG Display
Saiz
21.5
Permohonan
IA
Resolusi
1920×1080
Komposisi
LCM
Kecerahan
250
CR
1000:1
Warna
16.7M
Lampu latar
WLED
Antara muka
LVDS
In Stock
3985
Spesifikasi

Nombor Bahagian LM215WF3-SLC1
JenamaLG Display
Saiz21.5
PermohonanIA
Resolusi1920×1080
KomposisiLCM
Kecerahan250
CR1000:1
Warna16.7M
Lampu latarWLED
Antara mukaLVDS
jenama panelLG Display
model panelLM215WF3-SLC1
jenis panel a-Si TFT-LCD , LCM
saiz panel21.5 inch
resolusi1920(RGB)×1080 , FHD
mod paparanIPS, Normally Black, Transmissive
kawasan aktif475.2×267.3 mm
garis besar495.6×292.2×11 mm
permukaanAntiglare, Hard coating (3H)
kecerahan250 cd/m² (Typ.)
nisbah kontras1000:1 (Typ.)
warna paparan16.7M (6-bit + Hi-FRC), CIE193172%
masa tindak balas14 (Typ.)(G to G)
sudut pandangan89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
kekerapan60Hz
jenis lampu13S4PWLEDWithout Driver
antara muka isyaratLVDS (2 ch, 8-bit), 30 pins
voltan masukan5.0V (Typ.)
permohonanIA
Model Keluarga
LM215WF1-TLA1 LG Display 21.5 1920×1080
LM215WF1-TLE1 LG Display 21.5 1920×1080
LM215WF2-SLD1 LG Display 21.5 1920×1080
LM215WF3-SLA2 LG Display 21.5 1920×1080
LM215WF3-SLC1 LG Display 21.5 1920×1080
LM215WF3-SLN1 LG Display 21.5 1920×1080
LM215WF4-TLE1 LG Display 21.5 1920×1080
LM215WF4-TRA1 LG Display 21.5 1920×1080
LM215WF5-SLA1 LG Display 21.5 1920×1080
LM215WF8-TLA1 LG Display 21.5 1920×1080
