| Nombor Bahagian | DMF-50773NF-FW |
| Jenama | Kyocera |
| Saiz | 5.4 |
| Permohonan | IA |
| Resolusi | 240×128 |
| Komposisi | LCM |
| Kecerahan | 100 |
| CR | 10:1 |
| Warna | Monochrome |
| Lampu latar | CCFL |
| Antara muka | CPU |
| jenama panel | OPTREX |
| model panel | DMF-50773NF-FW |
| jenis panel | FSTN-LCD , LCM |
| saiz panel | 5.4 inch |
| resolusi | 240×128 |
| mod paparan | STN, Black/White mode, Transmissive |
| kawasan aktif | 119.97×63.97 mm |
| garis besar | 170×105 mm |
| permukaan | |
| kecerahan | 100 cd/m² (Typ.) |
| nisbah kontras | 10:1 (Typ.) |
| warna paparan | Monochrome |
| masa tindak balas | 250/230 (Typ.)(Tr/Td) |
| sudut pandangan | |
| kekerapan | 70Hz |
| jenis lampu | 1 pcsCCFLWithout Driver |
| antara muka isyarat | 8-bit parallel, 20 pins |
| voltan masukan | 5.0V (Typ.) |
| permohonan | IA |
