LM185WH1-TLH1

LM185WH1-TLH1
LM185WH1-TLH1
LM185WH1-TLH1 thumb LM185WH1-TLH1 thumb
Jenama
LG Display
Saiz
18.5
Permohonan
DMPC
Resolusi
1366×768
Komposisi
LCM
Kecerahan
200
CR
600:1
Warna
16.7M
Lampu latar
CCFL
Antara muka
LVDS
In Stock
15813
Spesifikasi

Nombor Bahagian LM185WH1-TLH1
JenamaLG Display
Saiz18.5
PermohonanDMPC
Resolusi1366×768
KomposisiLCM
Kecerahan200
CR600:1
Warna16.7M
Lampu latarCCFL
Antara mukaLVDS
jenama panelLG Display
model panelLM185WH1-TLH1
jenis panel a-Si TFT-LCD , LCM
saiz panel18.5 inch
resolusi1366(RGB)×768 , WXGA
mod paparanTN, Normally White, Transmissive
kawasan aktif409.8×230.4 mm
garis besar430.4×254.6×13.5 mm
permukaanAntiglare, Hard coating (3H)
kecerahan200 cd/m² (Typ.)
nisbah kontras600:1 (Typ.)
warna paparan16.7M (6-bit + Hi-FRC), CIE193160%
masa tindak balas1.1/3.9 (Typ.)(Tr/Td)
sudut pandangan45/45/15/35 (Typ.)(CR≥10)(L/R/U/D)
kekerapan60Hz
jenis lampu2 pcsCCFLWithout Driver
antara muka isyaratLVDS (1 ch, 8-bit), 30 pins
voltan masukan5.0V (Typ.)
permohonanDMPC
Model Keluarga
LM185WH1-TLA1 LG Display 18.5 1366×768
LM185WH1-TLC5 LG Display 18.5 1366×768
LM185WH1-TLD3 LG Display 18.5 1366×768
LM185WH1-TLF1 LG Display 18.5 1366×768
LM185WH1-TLF4 LG Display 18.5 1366×768
LM185WH1-TLH1 LG Display 18.5 1366×768
LM185WH2-T2BB LG Display 18.5 1366×768
LM185WH2-TLA1 LG Display 18.5 1366×768
LM185WH2-TLD1 LG Display 18.5 1366×768
LM185WH2-TLE2 LG Display 18.5 1366×768
