LG Display LC470WUE-SEP1 lembaran data, spesifikasi, stok, aplikasi www.looklcd-my.com
LookLCD LookLCD


LC470WUE-SEP1

LC470WUE-SEP1
LC470WUE-SEP1
LC470WUE-SEP1 thumb LC470WUE-SEP1 thumb
Jenama
LG Display
Saiz
47
Permohonan
LCTV
Resolusi
1920×1080
Komposisi
LCM
Kecerahan
400
CR
1100:1
Warna
16.7M/1.06B
Lampu latar
EEFL
Antara muka
LVDS
In Stock
17512
Spesifikasi

Nombor Bahagian LC470WUE-SEP1
JenamaLG Display
Saiz47
PermohonanLCTV
Resolusi1920×1080
KomposisiLCM
Kecerahan400
CR1100:1
Warna16.7M/1.06B
Lampu latarEEFL
Antara mukaLVDS
jenama panelLG Display
model panelLC470WUE-SEP1
jenis panela-Si TFT-LCD , LCM
saiz panel47 inch
resolusi1920(RGB)×1080 , FHD
mod paparanIPS, Normally Black, Transmissive
kawasan aktif1039.68×584.82 mm
garis besar1096×640 mm
permukaanAntiglare (Haze 1%), Hard coating (2H)
kecerahan400 cd/m² (Typ.)
nisbah kontras1100:1 (Typ.)
warna paparan16.7M/1.06B (8-bit / 8-bit + FRC), CIE193172%
masa tindak balas5.0(Typ.)(G to G)
sudut pandangan89/89/89/89 (Min.)(CR≥10)(L/R/U/D)
kekerapan60Hz
jenis lampu20 pcsEEFLWithout Driver
antara muka isyaratLVDS (2 ch, 8/10-bit) , 51 pins
voltan masukan12.0V (Typ.)
permohonanLCTV
Model Keluarga
LC470WU1-SLA1 LG Display 47 1920×1080
LC470WUD-SCM1 LG Display 47 1920×1080
LC470WUE-SDP1 LG Display 47 1920×1080
LC470WUE-SEP1 LG Display 47 1920×1080
LC470WUF-SBF1 LG Display 47 1920×1080
LC470WUF-SCA2 LG Display 47 1920×1080
LC470WUF-SCA3 LG Display 47 1920×1080
LC470WUL-SBT1 LG Display 47 1920×1080
LC470WUN-SCA1 LG Display 47 1920×1080
LC470WUN-SDA1 LG Display 47 1920×1080
