LC470WUE-SDP1

LC470WUE-SDP1
LC470WUE-SDP1 thumb
Jenama
LG Display
Saiz
47
Permohonan
LCTV
Resolusi
1920×1080
Komposisi
LCM
Kecerahan
400
CR
1100:1
Warna
16.7M/1.06B
Lampu latar
EEFL
Antara muka
LVDS
In Stock
4667
Spesifikasi

Nombor Bahagian LC470WUE-SDP1
JenamaLG Display
Saiz47
PermohonanLCTV
Resolusi1920×1080
KomposisiLCM
Kecerahan400
CR1100:1
Warna16.7M/1.06B
Lampu latarEEFL
Antara mukaLVDS
jenama panelLG Display
model panelLC470WUE-SDP1
jenis panel a-Si TFT-LCD , LCM
saiz panel47 inch
resolusi1920(RGB)×1080 , FHD
mod paparanS-IPS, Normally Black, Transmissive
kawasan aktif1039.68×584.82 mm
garis besar1096×640 mm
permukaanAntiglare (Haze 10%), Hard coating (2H)
kecerahan400 cd/m² (Typ.)
nisbah kontras1100:1 (Typ.)
warna paparan16.7M/1.06B (8-bit / 8-bit + Dithering), CIE193172%
masa tindak balas5 (Typ.)(G to G)
sudut pandangan89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
kekerapan60Hz
jenis lampu18 pcsEEFLWithout Driver
antara muka isyaratLVDS (2 ch, 8/10-bit), 51 pins
voltan masukan12.0V (Typ.)
permohonanLCTV
