LG Display LC470DUT-SEF2 lembaran data, spesifikasi, stok, aplikasi www.looklcd-my.com
LookLCD LookLCD


LC470DUT-SEF2

LC470DUT-SEF2
LC470DUT-SEF2
LC470DUT-SEF2 thumb LC470DUT-SEF2 thumb
Jenama
LG Display
Saiz
47
Permohonan
LCTV
Resolusi
1920×1080
Komposisi
CELL
Kecerahan
0
CR
1300:1
Warna
16.7M
Lampu latar
No B/L
Antara muka
Mini LVDS
In Stock
13065
Spesifikasi

Nombor Bahagian LC470DUT-SEF2
JenamaLG Display
Saiz47
PermohonanLCTV
Resolusi1920×1080
KomposisiCELL
Kecerahan0
CR1300:1
Warna16.7M
Lampu latarNo B/L
Antara mukaMini LVDS
jenama panelLG Display
model panelLC470DUT-SEF2
jenis panel a-Si TFT-LCD , CELL
saiz panel47 inch
resolusi1920(RGB)×1080 , FHD
mod paparanIPS, Normally Black, Transmissive
kawasan aktif1039.68×584.82 mm
garis besar1046.68×594.02 mm
permukaanHard coating (2H), Reflection 2.0% (Max.)
kedalaman kaca0.50+0.50 mm
ketransmisian4.5% (Typ.)(with Polarizer)
nisbah kontras1300:1 (Typ.)
warna paparan16.7M (8-bit)
masa tindak balas4/4 (Typ.)(Tr/Td)
sudut pandangan89/89/89/89 (MIn.)(CR≥10)(L/R/U/D)
kekerapan240Hz
antara muka isyaratMini LVDS, 160 pins
voltan masukan12.0V (Typ.)(VLCD)
permohonanLCTV
Model Keluarga
LC470DUE-FGA3 LG Display 47 1920×1080
LC470DUE-SFR1 LG Display 47 1920×1080
LC470DUE-SFU2 LG Display 47 1920×1080
LC470DUN-SFU2 LG Display 47 1920×1080
LC470DUT-SEF2 LG Display 47 1920×1080
LC470EUD-SEF2 LG Display 47 1920×1080
LC470EUN-FFM1 LG Display 47 1920×1080
LC470EUN-SEM1 LG Display 47 1920×1080
LC470WU1-SLA1 LG Display 47 1920×1080
LC470WUN-SDA1 LG Display 47 1920×1080
