| Nombor Bahagian | LTA550HQ23-W |
| Jenama | Samsung |
| Saiz | 55 |
| Permohonan | LCTV |
| Resolusi | 1920×1080 |
| Komposisi | LCM |
| Kecerahan | 360 |
| CR | 4000:1 |
| Warna | 16.7M/1.07B |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama panel | SAMSUNG |
| model panel | LTA550HQ23-W |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 55 inch |
| resolusi | 1920(RGB)×1080 , FHD |
| mod paparan | SVA, Normally Black, Transmissive |
| kawasan aktif | 1209.6×680.4 mm |
| garis besar | 1229.4×704.2 mm |
| permukaan | Antiglare (Haze 2.3%), Hard coating (2H) |
| kecerahan | 360 cd/m² (Typ.) |
| nisbah kontras | 4000:1 (Typ.) |
| warna paparan | 16.7M/1.07B (8-bit / 8-bit + Dithering), CIE193170% |
| masa tindak balas | 8 (Typ.)(G to G) |
| sudut pandangan | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | WLEDEmbedded (LED Driver) |
| antara muka isyarat | LVDS (2 ch, 8/10-bit) |
| voltan masukan | 12.0V (Typ.) |
| permohonan | LCTV |
